3000W Peak 6000W DC 24V Modified Wave Power Inverter With Charger Voltage Display modified sine wave inverter with charger manufacturer from China Sun Gold Power Co,.Ltd

Payment Terms:	T/T,WU;paypal
Place of Origin:	Guangdong, China (Mainland)

Product Detail

Model No.: modified sine wave inverter...

Type: DC/AC Inverters

Output Power: >500W

ups: inverter with charger

Delivery Date: 15-30

Output Type: Single

Brand Name: http://www.sungoldpower.com

Specifications:
3000W offline UPS dc to ac inverter with battery charger
With Uninterruptible Power Source, Time of fully automatic converting 10ms.

Specifications:

3000W offline UPS dc to ac inverter with battery charger

With Uninterruptible Power Source, Time of fully automatic converting 10ms.

Features:

1)3000W continuous output power and 6000W surge power.

2)Suitable for mobile AC power used in car, household and industry.

3)High surge power to start difficult loads such as heavy-duty power tools, motor

4)Suitable for most AC-powered electronic equipment including computers, TV, icebox, and more.

5)Enjoy full and stable power with storage battery together.

6)It can save 1/3 charge time with pulse charge, good for saving charge time and high life for storage battery.

7)With Uninterruptible Power Source, Time of fully automatic converting 10ms

8) size: 35X15.0X12.5cm, Net weight:5.5kg

Invert part:

Rated power	3000w
output continuous power	3000w
output peak power	6000w
DC input voltage	24V
Working voltage	21-29V
Low voltage protection	18.5V-20.5V
Lack voltage alarm	19.5V-21V
Over-voltage protection	≥29V
DC input Fuse	25A*7
Output wave form	modified sine wave
output voltage	110V/120V/220V/230V/240V
Output frequency	50HZ/60HZ
Reserving efficency	≥ 85%
Overload protection	3000W-3600W
Short circuit protection	YES
Working temperature	-10°c- +50°c
Temperature protection	+60°c - +70°c
Green led indicator	Light(fully charge),flash(charging),extinguish(no AC supply or in AC input voltage protection station)

Charge Part:

Rate Power	3000W	3000W
AC output voltage	110V/120V	220V/230V/240V
AC inputfrequency	50HZ/60HZ	50HZ/60HZ
AC working voltage	85V-130V	170V-250V
AC input low voltage protection	≤75V	≤150V
AC input high voltage protection	≥130V	≥250V
AC input fuse	20A*2	20A
charge style	intelligent positive and negative pulse charge
charge process	prep charge. main charge.float charge. charge fully
charge current	Maximal 15A
charge voltage	29V-32V
Switching time from inverter to AC supply	≤10ms(no need to restart computer when connectedto computer
Switching time from AC supply to inverter	≤10ms( no need to restart computer when connected to computer
Conditional from inverter to AC supply	In the normalAC input voltage
Conditional from AC supply to inverter	No AC input or AC input protection happen
Yellow led indicator	Light(fully charge),flash(charging),extinguish(no AC supply or in AC input voltage protection station)
