156x156 Polycrystalline Solar Cell Panel 4.2W 2 Busbar

Payment Terms:	T/T,L/C;papal
Place of Origin:	Guangdong, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: 4.2w Polycrystalline Solar ...

Delivery Date: 10-30

Brand Name: http://www.sungoldpower.com...

Max. Power: 4.2w

Means of Transport: Air

Material: Polycrystalline Silicon

Number of Cells: 50/72/100/200

solar cell: solar panel

High conversion efficiencies resulting in superior
power output performance
Outstanding power output even in low light or high
temperatur

A Grade 156mm x 156mm polySolar cells, 50 piece for building solar panel !

Specification:

Material: Polycrystaline Class: grade A

Size: 156mm x 156mm (6) Type:2 busbar

Thickness:200 um Color: blue

Service life:30 years Standard:CE.TUV

Technical data:

Efficiency:16.5% Power: 4.09W-4.25W

Vmp:0.53V Imp:7.81A

Voc:0.63V Isc:8.29A

Features:

High conversion efficiencies resulting in superior
power output performance
Outstanding power output even in low light or high
temperature conditions
Optimized design for ease of soldering and lamination
Long-term stability, reliability and performance
Low breakage rate

Color uniformity

Production and Quality Control :

Precision cell efficiency sorting procedures
Stringent criteria for color uniformity and appearance
Reverse current and shunt resistance screening
REACH-SVHC and RoHS compliant, ISO9001, ISO14001 and OHSAS 18001 certificated
