2KW 48V PWM High Power Solar Charge Controller Regulator LCD Display

Payment Terms:	T/T,L/C;paypal
Place of Origin:	Guangdong, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: 2KW 48V PWM High Power Sola...

Delivery Date: 10-60

Certification: CE

Brand Name: http://www.sungoldpower.com...

1KW solar charger controller: PWM solar regulator

Means of Transport: Ocean,Air

Type: Others

Usage: Others

solar charger controller: high power solar charger co...

Superior military-grade components to ensure the product stability.
Perfect protection function
PWM stepless unload mode
LCD display

Product Introduction

Solar controller is control device which can control solar panel and transform solar energy into electricity then store to the battery bank . Solar controller is the most important part in off-grid system, whose performance has much effect onlife expectancy and operation of the whole system, especially the battery expectancy. Or life span of battery will be shortened by over charge or over discharge.

Performance Feature

·Superior military-grade components to ensure the product stability.

·Perfect protection function, thus the system has higher reliability.

·Check and set all operation parameters as requirement from LCD display.

·PWM stepless unload mode, which burn the excess power into Dump load, making the battery charging in best status.

Technical Date

Product Model
SG20-48-N00
SG20-96-N00
SG20-110-N00
SG20-120-N00
SG20-220-N00
Rated Battery Voltage
48V
96V
110
120V
220V
Rated Solar Input Power
2kW
2kW
2kW
2kW
2KW
Floating Charge Voltage
58V
116V
133V
145V
266V
Max Open Circuit Voltage
100V
200V
230V
250V
458V
Display Mode
LCD
Quiescent Current
≤20mA
Ambient Temperature &     Humidity
-20+55℃/3585%RH(Without Condensation)
Communication Function  (Optional)
RS232 (Optional: RS485\ RJ45\ GPRS )
Temperature Compensation Function(Optional)
-4mV/℃/2V ,–35℃--+80℃, Precision:±1℃
Dimensions   (L x W x H)
440×300×170mm
Net Weight
8 kg
In order to serve our customers better, our company can adjust parameter configuration according to customer's requirement.

Declare: Our company reserves the right to change products. Design and specification are subject to changewithout prior notice.

Optitional Function

Temperature Compensation Function
RS communication function
Dry-contact signal Function
SD card storage Function
