6000W DC to AC Pure Sine Wave Power Inverter manufacturer from China Sun Gold Power Co,.Ltd

Payment Terms:	T/T,WU;paypal
Place of Origin:	, China (Mainland)

Product Detail

Product name:6000W DC to AC Pure Sine Wave Inverter
DC12V/24V/48V, AC100V/110V/120V or AC220V/230V/240V

Characteristics:

High Transform efficiency

Pure sine wave inverter

Anodized aluminum case provides durability

Built-out fuses

With USB output

Remote Switch

Soft start function

Built in cooling fan

With battery cable

Over/low battery voltage protection

DC/AC Isolated

Function details:

Model	SG-6000S
Rated power	6000W	6000W	6000W	6000W	6000W		6000W
Peak power	12000W	12000W	12000W	12000W	12000W		12000W
DC input voltage	12V	24V	48V	12V	24V		48V
AC output voltage	100VAC,110VAC,120VAC			220VAC, 230VAC, 240VAC
No-load current	<2.0A
AC output frequency	50HZ±0.5Hz ,60HZ±0.5Hz
AC output waveform	Pure Sine Wave power inverter
Waveform distortion	THD3%(Linear load)
Efficiency	85%	88%	90%	85%		88%	90%
DC input voltage range	10.5-15V	21-30V	42-60V	10.5-15V		21-30V	42-60V
Low Voltage Alarm	10.5+/-0.3V	21+/-0.3V	42+/-0.3V	10.5+/-0.3V		21+/-0.3V	42+/-0.3V
Low Voltage Shutdown	10+/-0.3V	20+/-0.3V	40+/-0.3V	10+/-0.3V		20+/-0.3V	40+/-0.3V
Over Voltage Protection	15.5+/-0.5V	31+/-1V	62+/-2V	15.5+/-0.5V		31+/-1V	62+/-2V
Low Voltage Recovery	12+/-0.5V	24+/-1V	48+/-2V	12+/-0.5V		24+/-1V	48+/-2V
Over Voltage Recovery	14.8V	29.5V	59V	14.8V		29.5V	59V
Protective Function	Low/Over voltage		LED Red light, automatic recovery
	Over load		LED Red light, automatic recovery
	Over temperature		LED Red light, automatic recovery
	Short circuit		LED Red light, automatic recovery
	Input reverse connection		Fuse Burn-out
Working Temp.	0-40C
Storage Temp. Humidity	(-30)-70C
Dimension	692514.5cm
Net Weight	18Kg
Warranty	12 Months
