10A Solar Charge Controller Regulator 12/24V With Lighting and Timer Sensor SG-SCCPWM10 manufacturer from China Sun Gold Power Co,.Ltd

Place of Origin:

Guangdong, China (Mainland)

Product Detail

Model No.: SG-SCCPWM10

solar charger controller: pwm solar charger controlle...

Brand Name: http://www.sungoldpower.com...

Detailed Product Description:
Rated Current:10A
System Voltage:12/24V Auto Work
Model selection:
10A 12/24V AUTO
Ideal for off-grid solar sy

Features:

1.Intelligent System Optimum Controller

2.High efficient Series PWM charging with temperature compensation

3.Compact size

4.Use MOSFET as electronic switch, without any mechanical switch

5.Digital LED menu, only one key solve all setting simple

6.Widely used, automatically recognize day/night

7.Intelligent timer function with 1-15 hours option

8.Unique dual timer function, enhance the flexibility of street light system.

9.Gel, Sealed and Flooded battery type option

10.Load status display

11.Big terminals and big distance between terminals

12.Electronic protection:Overheating, over charging, over discharging, overload, and short circuit

13.Reverse polarity protection : Any combination of solar module and battery

14.Load work mode: Light ON+Dual timer, Dusk to Dawn, Test, ON/OFF

Technical Specification:

Model	SG-SCCPWM10
Rated Current	10A
System Voltage	12/24V auto work
Max Battery Voltage	32V
Charge Circuit Voltage Drop	≤0.26V
Discharge Circuit Voltage Drop	≤0.15V
Over Load Protection	1.25 times of rated current for 60 seconds,1.5times for 5 seconds
Short Circuit Protection	3.5 times of rated current
Self- consumption	Max.6mA
Working Temperature	-35°C to +55°C industrial
Equalize Charging Voltage	14.6V; x2/24V
Boost Charging Voltage	14.4V; x2/24V
Float Charging Voltage	13.8V; x2/24V
Boost Reconnect Charging Voltage	13.2V; x2/24V
Temperature Compensation	-30mV/°C/12V
Under Voltage Warning Voltage	12.0V; x2/24V
Low Voltage Disconnect Voltage	11.1V; x2/24V
Low Voltage Reconnect Voltage	12.6V; x2/24V
Equalize Duration	2 hours
Boost Duration	2 hours
Overall dimension	140 x 65 x 34mm
Terminals	4 mm2
Enclosure	IP30
