4000W Peak 12000W Split Phase 120V 240V Pure Sine Wave Inverter Charger 35A 48V

Payment Terms: T/T,WU;paypal
Place of Origin: Guangdong, China (Mainland)
inquire
Add to My Favorites
HiSupplier Escrow
Share |

Product Detail

Model No.: 4000w split phase inverter ...
Type: DC/AC Inverters
Output Power: >500W
Size: 598mm*218mm*179mm
inverter with charger: ups
Delivery Date: 15-30
Output Type: Single
Brand Name: http://www.sungoldpower.com...
Weight: 38kg

Pure sine wave output, available for sensitive load
low freqency with copper material
4-step progressive charging, 7 battery type selector
Fast and

 4000W PEAK 12000WPURE SINE WAVE INVERTER / 35AMP CHARGER WITH LCD SCREEN
it is low freqency inverter , high quality !power any applicance !
With 35AMP charger, perform as a UPS !38kg !!

1.Input:240VAC, Output: 120/240VAC
2. Split phase
3. Battery DC: 48V
4. With Remote Control

Application:
all kinds of home appliance, office equipment, solar power system, and other equipments which use single phase power.
Features:
Pure sine wave output, available for sensitive load
low freqency with copper material
4-step progressive charging, 7 battery type selector
Fast and powerful charger with35A
Accept generator's energy output
High power factor
Automatically transfer between battery and line modes
Microprocessor control guarantees high reliability
Bypass without battery connected
Remote control function
Protection against:
Over load, over temperature, over charging, low battery
Reverse connection (optional by hard connector)
Blackouts

Model No.
SG-4000C
Nominal Power
4000W
Peak Power
12000W
AC input
240VAC
AC output
AC120V and AC 240V
Battery Voltage
48V
Phase & waveform
Split Phase
Frequency
50Hz or 60Hz (auto sensing)
Line Low Transfer
47Hz for 50Hz,57Hz for 60Hz
Line high Transfer
55Hz for 50Hz,65Hz for 60Hz
Voltage Regulation
±10%rms(bypass mode sync to input)
Frequency
50/60Hz±0.3Hz(bypass mode sync to input)
Crest Power
3 times of ratings
Short Circuit Protection
Yes, shutdown after 10 minutes
Power Factor
0.9-1.0
DC Input
Battery Voltage
48V
Minimum Start Voltage
40V
Low Battery Alarm
42V
Low Battery Transfer
40V
High Voltage Alarm
64V
Max Charging Current
35A
Over Charge Voltage
62.8V
Transfer Efficiency
line Mode
95%
Battery Mode
88%
power saver
Available when the load is less than 25 Watts
Indicators
7-LED Display
From the right to the left,LED1 line mode (green lighting)\LED2 inverter mode
(green lighting)\LED3 charging mode(yellow lighting)\LED4 Fully charged
(green lighting)\LED5 over heat shutdown(red lighting)\LED6 Overloaded
shutdown(red lighting)\LED7 Saving Mode(green lighting)
3-LED Display
Charging Mode(green lighting)\inverter mode(green lighting)\Alarm(red lighting)
Switch selector
Saving Mode is on/off when push the switch forwards/backwards,   keeping it horisontal is
turning the inverter off.
Audible Alarm
Sounding when the heatsink's tem is over 105℃ and shutdown after 30 seconds.
Protections
low battery\over charging\over temp\over load
Enviromental
Operating Environment
0-40℃,0-90%RH(non-condensing)
Audible Noise
60dB
Size
598mm*218mm*179mm
Net Weight(KG)
38kg
