1000W Horizontal-Axis wind turbine generator 24V AC 5 blades 1000W Horizontal-Axis wind turbine generator manufacturer from China Sun Gold Power Co,.Ltd

1000W Horizontal-Axis wind turbine generator 24V AC 5 blades

Payment Terms:	T/T,L/C;paypal
Place of Origin:	Guangdong, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: 1000W Horizontal-Axis wind ...

Delivery Date: 10-60

Brand Name: http://www.sungoldpower.com...

1000w wind turbine generator: 24v wind turbine generator

Means of Transport: Ocean,Air

Type: Wind Power Generator

wind turbine: Horizontal-Axis Wind Turbin...

1, starting with low wind speed, high output capactiy,low vibration
2. blades using new technology precision injection molding

Feature:

1, starting with low wind speed, high output capactiy,low vibration

2. blades using new technology precision injection molding, together with the aerodynamic design and structural design.

3. permanent magnet generator rotor using patented alternator, together with the special stator design, effectively reduce the generation of resistance torque,

4. High efficiency of anti-wind ability, High cost-effective wind generator system for home

Parameter

Rated power: 1000W

Battery voltage: 24V

Rated current: 42A

Max power: 1200W

Output: AC output

Number of blade: 5 pcs

Starting wind speed: 3m/s

Cut-in wind speed: 3.5m/s

Cut-out wind speed: 15m/s

Security wind speed:40m/s

Rated wind speed: 12.5m/s

Engine: Three-phase permanent magnel AC generator

Rotor diameter: 2200mm

Blade material: Carbon fiber reinforced plastics

Output line anti-winding device: Overall three-phase commutator

Over-speed wind protection: Tip stall protection + Electromagnetic brake

Life span:15 years

Equipment surface protection: Aluminum oxide + plastic coating

Working temperature: -45°C-70°C

packing dimension: 1100*235*110*mm

N.W.: 29kg

G.W.: 32.6kg

Quality And Warranty:

1. CE TUV and ROHS certificate

2.12 month warranty

3. the buyer is responsible for the return post mail cost

4.15 days refund and 20 days exchange after receiving the product
